384_well Low Volume Magnet Plate
384-Well Low Elution Post Magnet Plate with Integrated Cushion Base
$645.00
-
+
Add To Cart

Permagen Labware

384_well Low Volume Magnet Plate
384_well Low Volume Magnet Plate

384-Well Low Elution Post Magnet Plate with Integrated Cushion Base

$645.00

Worldwide shipping available

The Permagen 384-well Low Elution post magnet plate was designed for use in manual or automation applications for high throughput PCR. Magnetic beads are pulled midway up onto well wall to help eliminate accidental bead pellet disruption and to achieve lower volumes. Includes integrated cushion base for maximum recovery during automation

Guaranteed Safe Checkout
SKU: MSP384LE Categories: ,
  • No-Risk Money Back Guarantee!
  • No Hassle Refunds
  • Secure Payments
Request a quote
Purchase two or more and save 10% Purchase 10+ for a 15% discount
Read About Cushion Base Here

384-Well Low Elution Plate with Integrated Cushion Base

The Permagen 384-well post magnet plate was designed for use in manual or automation applications for Low Elution volumes down to 4 µL, but can still handle up to a full 39 µL

Features

Low Elutions

As low as 4 µL from 384-well PCR plates

Fast Separations

Strong NdFeB Ring Magnets ensure fast, precise separations

Integrated Cushion

Cushion base compensates for labware and consumable inconsistencies

Robot Friendly

SBS/ ANSI footprint to fit into all liquid handling robots

Unique Magnet Design

  • Unique magnet structure allows for 384-Well Low Elution applications
  • Fast bead separations using strong NdFeB magnets
  • Compatible with standard 384-Well PCR plates
  • Side cuts allowing liquid handling robot gripper
  • ANSI/ SBS compliant footprint to fit into all liquid handlers
  • Integrated cushion base to help compensate for robot and labware inconsistences
  • Made in the USA

Compatibility

This magnet was designed to be compatible with common microplates, all liquid handler robots, and any magnetic beads

FAQ

Aluminum is much easier to make precision products out of then plastic. It stays flat and wont warp. This leads to more consistent results

For a 384-Well PCR plate, the beabs will be pulled to the side of each well.

This plate accepts 384-Well PCR plates



Yes, this plate has a standard SBS/ ANSI compliant footprint to fit into any platforms, the only limitations would be the height on smaller units

Yes, all Permagen products are available to be private labeled with your company logo/ part numbers for resale

Products can be purchased at our online shop,  via. purchase order, over the phone, or by requesting a quote

Permagen 384-well Low Elution and standard 384-well comparison

On the left is our Low Elution 384-well plate with the magnets sitting much lower than our standard 384-well plate on the right allowing for lower volumes to be separated

Join Our
Newsletter

We only send out new product announcements, sale notifications, and tradeshow dates.

Features

Compatible with most 384-well pcr microplates
strong magnets for fast separations
volumes 5 µL to 39 µL
SBS footprint to fit most liquid handlers
Specifications

Size = 127.75mm x 85.47mm x 20.7mm tall over magnets
Weight = 568g
Magnets = 40 MGO NdFeB
Country of origin = USA
For Research Use Only
