0.2 mL PCR Strip Magnetic Separator 24 tube


Permagen’s 0.2 mL PCR Tube Magnetic rack is designed for magnetic bead separations from 0.2 mL individual tubes, 8-strip, or 12-strip PCR. Tubes are held at an angle and beads will be pulled to back wall allowing easy aspiration and tip tracking down the front wall of the tubes without disturbing bead pellet. Accommodates any common PCR strips or individual PCR tubes.

Guaranteed Safe Checkout
Purchase two or more and save 10% Purchase 10+ for a 15% discount
MSR812 PCR Strip Separation Rack Magnet for 0.2 mL

0.2 mL PCR Magnetic Separation Rack

This 24 tube, 0.2 mL PCR Separation Rack is ideal for all protocols requiring a strong magnet for fast, precise separations from PCR Strips or Individual Tubes



Held to higher standards and made from solid aluminum for consistent, trouble-free use

Fast Separations

Strong NdFeB Disc Magnets ensure fast, precise separations

Unique Design

Angled tube holes allow easy tip tracking down the tube wall without accidental bead aspiration

Lab Friendly

Used in many lab protocols currently

The extras come standard!

  • Compatible with standard 0.2 mL PCR tubes. Individual, 8-strip, and 12-strip
  • Fast bead separations using strong NdFeB magnets
  • Up to 0.2 mL working volumes
  • Angled tube holes for easy pipetting without bead loss
  • Rubber feet to help prevent slipping while working on bench
  • Made in the USA


This magnet was designed to be compatible with common PCR tubes, and all magnetic beads

0.2 mL Magnetic Beads Separations PCR Strip


Yes, all but a few of our products are aluminum. We find that a much better performing product can be achieved this way. Others use plastic for one reason… it’s cheap!

Yes, this rack was previously called “0.2 mL PCR Strip Magnetic Separation Rack 8 or 12″,  there was some confusion about ordering an 8 or 12 strip rack, but it meant it was capable of both

The minimum volume of this rack is 30 µL. If you need lower, our MSRLV08 goes down to 5 µL and can be found here

We have separated a full 0.2 mL, undiluted, Ampure® XP beads in under three minutes.

Yes, all Permagen products are available to be private labeled with your company logo/ part numbers for resale

Products can be purchased at our online shop,  via. purchase order, over the phone, or by requesting a quote

Join our mailing list

Never miss any new products. We only send out new product releases and show announcements


Compatible with any magnetic beads
Super strong magnets for fast, precise separations
Ideal for NGS
Process up to 24 samples from PCR strips or individual tubes
Multichannel pipetting compatible
Rubber feet to reduce slipping


Size: 108mm Long x 34.8mm Tall x 37.6mm
Weight: 130g
Magnets: 50 MGO NdFeB
Country of origin: USA
For Research Use Only


DNA/RNA purification
PCR cleanup
ChIP assays
