Permagen Labware

32 Tube X 0.2 mL PCR Strip Magnetic Separator


Permagen’s 32-tube PCR Separation rack features all of the same aspects of our MSR812 rack for easy protocol transition for labs wishing to scale up to four PCR strips at a time, or up to 32 individual PCR tubes

Guaranteed Safe Checkout
Purchase two or more and save 10% Purchase 10+ for a 15% discount

0.2 mL PCR Magnetic Separation Rack

This 32 tube, 0.2 mL PCR Separation Rack is ideal for all protocols requiring a strong magnet for fast, precise separations from PCR Strips or Individual Tubes.



Held to higher standards and made from solid aluminum for consistent, trouble-free use

Fast Separations

Strong NdFeB Disc Magnets ensure fast, precise separations

Unique Design

Angled tube holes allow easy tip tracking down the tube wall without accidental bead aspiration

Lab Friendly

Used in many lab protocols currently. Same as our MSR812 product with the added capacity

0.2 mL Magnetic Beads Separations PCR Strip

The extras come standard!

  • Compatible with standard 0.2 mL PCR tubes. Individual, 8-strip, and 12-strip
  • Fast bead separations using strong NdFeB magnets
  • Up to 0.2 mL working volumes
  • Angled tube holes for easy pipetting without bead disturbing beads
  • Rubber feet to help prevent slipping while working on bench
  • Made in the USA


This magnet was designed to be compatible with common PCR tubes, and all magnetic beads


Yes, all but a few of our products are aluminum. We find that a much better performing product can be achieved this way. Others use plastic for one reason… it’s cheap!

Yes, the caps shouldn’t be in you way at all

The minimum volume of this rack is 30 µL. If you need lower, our MSRLV08 goes down to 5 µL and can be found here

We have separated a full 0.2 mL, undiluted, Ampure® XP beads in under three minutes. Most protocols will take even less time

Yes, all Permagen products are available to be private labeled with your company logo/ part numbers for resale

Products can be purchased at our online shop,  via. purchase order, over the phone, or by requesting a quote

Join our mailing list

Never miss any new products. We only send out new product releases and show announcements


Compatible with any magnetic beads
Super strong magnets for fast, precise separations
Ideal for NGS
Process up to 32 samples from PCR strips or individual tubes
Multichannel pipetting compatible
Rubber feet to reduce slipping


Size: 149.9mm x 37.6mm x 33.0mm tall
Weight: 180g
Magnets: 50 MGOe NdFeB
Country of origin: USA
For Research Use Only


DNA/RNA purification
PCR cleanup
ChIP assays

32 position 0.2 mL PCR Separator rack32 Tube X 0.2 mL PCR Strip Magnetic Separator
